Aluminium Push Button Box

Name: Aluminium Push Button Box
Brand: SEGIBIZ
SKU: PRD-09

AL die-cast push button enclosures — 1 to 4 holes, or none.

Documentation

Line Code

PRD-09

The module in detail.

Very solid and light, because it is manufactured by the AL die-casting method. Various kinds of adopting holes are available from one hole to four holes, plus a product without a hole. (22Φ, 25Φ, 30Φ)

Specification

01Material: Aluminium die-cast (AL diecasting)

Feature Set

F-01AL die-cast construction — solid and light
F-02Adopting holes from one to four holes
F-03Hole-less variant available
F-04Hole sizes 22Φ, 25Φ, 30Φ

Applications

Emergency stop stationsOperator control pointsMachine control panels

[B]Model Register

16 production models on file.

Dimensions and masses as published. Download the DWG floor plan for your CAD environment.

Aluminium Push Button Box models with dimensions and CAD downloads
Model	Type	Size (mm)	Weight	Floor Plan
SG-CB-0001	No hole	80 × 90 × 70	385 g	DWG
SG-CB-2201	AL die-cast	80 × 90 × 70	385 g	DWG
SG-CB-2501	AL die-cast	80 × 90 × 70	385 g	DWG
SG-CB-3001	AL die-cast	80 × 90 × 70	385 g	DWG
SG-CB-0002	No hole	80 × 135 × 70	481 g	DWG
SG-CB-2202	AL die-cast	80 × 135 × 70	481 g	DWG
SG-CB-2502	AL die-cast	80 × 135 × 70	481 g	DWG
SG-CB-3002	AL die-cast	80 × 135 × 70	481 g	DWG
SG-CB-0003	No hole	80 × 180 × 70	561 g	DWG
SG-CB-2203	AL die-cast	80 × 180 × 70	561 g	DWG
SG-CB-2503	AL die-cast	80 × 180 × 70	561 g	DWG
SG-CB-3003	AL die-cast	80 × 180 × 70	561 g	DWG
SG-CB-0004	No hole	80 × 220 × 70	686 g	DWG
SG-CB-2204	AL die-cast	80 × 220 × 70	686 g	DWG
SG-CB-2504	AL die-cast	80 × 220 × 70	686 g	DWG
SG-CB-3004	AL die-cast	80 × 220 × 70	686 g	DWG

* Comparing with the real product, dimensions may show a minute gap.

[D]Documentation

Drawings & catalogs.

Official documentation mapped to this product line.

PDFSEGIBIZ Full Catalog 2020Catalog (PDF) · CAT-001

DWGSG-CB-0001 (No hole)Aluminium Push Button Box · APB-01

DWGSG-CB-2201Aluminium Push Button Box · APB-02

DWGSG-CB-2501Aluminium Push Button Box · APB-03

DWGSG-CB-3001Aluminium Push Button Box · APB-04

DWGSG-CB-0002 (No hole)Aluminium Push Button Box · APB-05

DWGSG-CB-2202Aluminium Push Button Box · APB-06

DWGSG-CB-2502Aluminium Push Button Box · APB-07

DWGSG-CB-3002Aluminium Push Button Box · APB-08

DWGSG-CB-0003 (No hole)Aluminium Push Button Box · APB-09

DWGSG-CB-2203Aluminium Push Button Box · APB-10

DWGSG-CB-2503Aluminium Push Button Box · APB-11

DWGSG-CB-3003Aluminium Push Button Box · APB-12

DWGSG-CB-0004 (No hole)Aluminium Push Button Box · APB-13

DWGSG-CB-2204Aluminium Push Button Box · APB-14

DWGSG-CB-2504Aluminium Push Button Box · APB-15

DWGSG-CB-3004Aluminium Push Button Box · APB-16

Open full resource center
